3. MAINTENANCE MENUS
Upper display Lower display Details Memory
L_DUTY DENS-M V01=***HS01=***H 01-03:First processing for averaging
density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
L_DUTY DENS-C V01=***HS01=***H 01-03:First processing for averaging
density
04-06: Second processing for averaging
density
V0X: Density sense value [HEX]
S0X: Density detection value [HEX]
SRAM
V02=***HS02=***H
V03=***HS03=***H
V04=***HS04=***H
V05=***HS05=***H
V06=***HS06=***H
FINAL DENS-K VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-K
SRAM
FINAL DENS-Y VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-Y
SRAM
FINAL DENS-M VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-M
SRAM
FINAL DENS-C VX=***H SX=***H The same value as V06 and HS06 of
L_DUTY DENS-C
SRAM
DB DENS VALUE VK=**** VY=**** Not used SRAM
DB DENS VALUE VM=**** VC=**** Not used SRAM
DELTA-K 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-K 04=**** 05=**** 06=**** Not used SRAM
DELTA-K 07=**** 08=**** 09=**** Not used SRAM
DELTA-Y 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-Y 04=**** 05=**** 06=**** Not used SRAM
DELTA-Y 07=**** 08=**** 09=**** Not used SRAM
DELTA-M 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-M 04=**** 05=**** 06=**** Not used SRAM
DELTA-M 07=**** 08=**** 09=**** Not used SRAM
Upper display Lower display Details Memory
DELTA-C 01=**** 02=**** 03=**** 01:Light adjustment value [DEC]
02: DB adjustment value (First)[ DEC]
03: DB adjustment value (Second) [DEC]
SRAM
DELTA-C 04=**** 05=**** 06=**** Not used SRAM
DELTA-C 07=**** 08=**** 09=**** Not used SRAM
DENS-K 100%=***H OD= **.**** Result of Black detections at multiple
points
SRAM
DENS-K 85%=***H
DENS-K 70%=***H
DENS-K 50%=***H
DENS-K 30%=***H
DENS-K 15%=***H
DENS-Y 100%=***H OD= **.**** Result of Yellow detections at multiple
points
SRAM
DENS-Y 85%=***H
DENS-Y 70%=***H
DENS-Y 50%=***H
DENS-Y 30%=***H
DENS-Y 15%=***H
DENS-M 100%=***H OD= **.**** Result of Magenta detections at multiple
points
SRAM
DENS-M 85%=***H
DENS-M 70%=***H
DENS-M 50%=***H
DENS-M 30%=***H
DENS-M 15%=***H
DENS-C 100%=***H OD= **.**** Result of Cyan detections at multiple
points
SRAM
DENS-C 85%=***H
DENS-C 70%=***H
DENS-C 50%=***H
DENS-C 30%=***H
DENS-C 15%=***H
BEFORE STD=***H DET=***H ADJ=**H Standard value before sensitivity
adjustment, measured value, adjustment
value
SRAM
AFTER STD=***H DET=***H Standard value after sensitivity
adjustment, measured value,
SRAM
• Results will be stored as described in memory filed.
• The contents in SRAM are deleted when the test starts, and values detected at the normal
competition or until the machine stops due to errors are written.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
