Oki MC873dn - Page 268

Oki Data CONFIDENTIAL
45850101TH Rev.1
6-17
6. CONNECTION DIAGRAMS
Unit Electrical circuit diagram, connection Part outside view Resistance value
Duplex print motor
1
3
RED
(A)
4
6
YELLO
W
(B)
WHITE
(B)
COLOR OF
LEAD
COLOR OF
LEAD
BLUE
(A)
PIN No.
PHR-6
PIN No.
PHR-6
PHR-6 connector
Between pin-1 and pin-3 : 3.2
Ω
Between pin-4 and pin-6 : 3.2
Ω
2nd, 3rd and 4th
tray hopping motor
M
1
2
3
4
Between pin-1 and pin-2 : 3.4
Ω
Between pin-3 and pin-4 : 3.4
Ω
