Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-6
2. TROUBLESHOOTING PROCEDURES
No. Category PJL Status
Code
Panel messages Description
19 Normal 10003 Warming up Warming up.
20 Normal 10963 Warming up. Indicates that printing has been suspended for a
while due to high temperature of the drum, or the
printer is in a wait state to cope with heat at the
time of switching narrow paper to wide paper.
21 Normal 10094 The MFP in power save mode.
LCD back light is turned off.
Green LED is turned on.
22 Normal 10058 Preparing ... Executing Auto Color Adjusting
23 Normal 10994
10988
Preparing ... Executing Auto Density Adjustment.
Status code 10988 corresponds to density
reading , thereto 10994 corresponds to density
adjusting.
24 Normal 40988 PU downloading ... Downloading PU F/W (This is not user-level error)
This function is secret to users. Therefore, this
status does not occur in a user environment.
It occurs during downloading firmware of option
tray.
25 Normal 10881 Updating firmware.
Do not turn OFF
the power.
Downloading scanner unit (Scanner, Fax, Panel)
FW.
26 Normal 30956 Wait a moment.
Network
Configuration
writing ...
This appears during the NIC configuration data is
storing into the flash memory, as the setting was
changed.
27 Normal 30993 Wait a moment.
Network initializing
...
This appears when the NIC initialization is
occurred, as the setting was changed.
28 Normal 10894 Cancelling ... Indicates that copy job is cancelling.
No. Category PJL Status
Code
Panel messages Description
29 Normal 10863 Scanning ... Indicates that it is scanning of documents.
The unit of "Page" is "Impression".
In duplex scanning, "Page" counter is increased
by 1 when the front side of sheet scanning
started, and the counter is increased by 1 when
the back side scanning started.
%LOCATION_INFO%: Location Information (
（Scan To E-mail, Scan To Network PC only)
%SCAN_PAGE%: the number of current
scanning page.
%DOC_SIZE%: Document size
Scan Size setting is "Auto": the detected
document size.
Scan Size setting isn't "Auto": the selected scan
size.
--------------------------------------------
Indicates that it is scanning of documents by
Scan To USBMemory.
The unit of "Page" is "Impression".
In duplex scanning, "Page" counter is increased
by 1 when the front side of sheet scanning
started, and the counter is increased by 1 when
the back side scanning started.
%SCAN_PAGE%: the number of current
scanning page.
%DOC_SIZE%: Document size
Scan Size setting is "Auto": the detected
document size.
Scan Size setting isn't "Auto": the selected scan
size.
--------------------------------------------
Indicates that it is scanning of documents by
Push Scan/PC Scan.
%AP_INFO%: Selected application setting.
While a document is scanned by FAX memory
transmission, status LED does not illuminate
because this status is not raise.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
