Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-30
2. TROUBLESHOOTING PROCEDURES
Panel display Cause Check details Result Solution
Inspection is
required.
056:Error
Controller unit
cannot detect
the hard disk
Power off the MFP and attach
the hard disk and power on
the MFP.
Power OFF/ON
057:Error
Detect the time
out between the
Controller unit
and scanner unit
01 : No ACK for
read beginning
command
02 : No ACK
for read cancel
command
03 : No ACK
for SIP cancel
command
Record the figures on the
lower right side of the LCD,
and cycle the power.
Power OFF/ON
058:Error
Detect the error
at scanner
control section
01 : SIP internal
error
02 : S
ｃａ
ｎ
Model internal
error
03 : SPB internal
error
Record the figures on the
lower right side of the LCD,
and cycle the power.
Power OFF/ON
059:Error
Detect the
communication
error between
the Controller
unit and scanner
unit
Record the figures on the
LCD, and close the error
display.
Inspection is
required.
067:Error
Detect the
communication
error with the
Sleep Mode
interface
supervisor
program.
Does this error recur? Ye s
Cycle the power.
Replace the CU/PU board.
Inspection is
required.
069:Error
Malfunction of
the NIC chip was
detected.
Does this error recur? Ye s
Cycle the power.
Replace the CU/PU board.
Power OFF/ON
070:Error
A PSE firmware
error was
detected.
If display the address on the
LCD, record the figures and
close the error display and
cycle the power.
Panel display Cause Check details Result Solution
Power OFF/ON
072:Error
I/F error between
CU and PU
Record the figures on the
lower right side of the LCD,
and cycle the power.
Power OFF/ON
073:Error c/
xxxxxxxx
Detect the Video
circuit over run.
Record the figures on the
lower right side of the LCD,
and cycle the power.
Power OFF/ON
075:Error c/
xxxxxxxx
Video error.
An error was
detected in
expanding image
data.
Power OFF/ON
077:Error
VIC Illegal
Decomp Error Does this error recur? Ye s
Cycle the power.
Replace the CU/PU board.
Inspection is
required.
078:Error
Communication
Error with
Operator Panel
Unit
Does this error recur? Ye s
Cycle the power.
Replace the CU/PU board.
Power OFF/ON
080:Error
Failed to access
to the parameter
storage
Does this error recur? Ye s
Cycle the power.
Replace the CU/PU board.
Inspection is
required.
081:Error
Parameter
matching check
error
Format the EEPROM , Flash
and need the initialize.
Inspection is
required.
090:Error
Detect the error
at stapler unit.
Replace the stapler unit or
CU/PU Board,and cycle the
power.
Inspection is
required.
104:Error
An engine
EEPROM read/
write error was
detected at
power on
Inspection is
required.
105:Error
Not detect the
EEPROM at
power on
Inspection is
required.
106:Error
Detect the error
at engine control
logic
Cycle the power.
Inspection is
required.
111:Error
A duplex unit for
another model
was detected
Is a duplex unit provided
for this model installed?
No Install a correct duplex unit.
Inspection is
required.
112:Error
A Tray2 for
another model
was detected.
Is a Tray2 provided for
this model installed?
No Install a correct Tray2.
Inspection is
required.
113:Error
A Tray3 for
another model
was detected.
Is a Tray3 provided for
this model installed?
No Install a correct Tray3.

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
