Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-31
2. TROUBLESHOOTING PROCEDURES
Panel display Cause Check details Result Solution
Inspection is
required.
114:Error
A Tray4 for
another model
was detected.
Is a Tray4 provided for
this model installed?
No Install a correct Tray4.
Inspection is
required.
120:Error
PU cooling FAN
error
Is the FAN connector
connected correctly?
No
Ye s
Check to make sure
connection of the FAN
connector.
Replace the FAN motor.
Inspection is
required.
121:Error
High voltage
power supply
interface error
Is the cable connecting
the CU board to the
high voltage power
supply unit connected
properly?
Is there any defective
contact point?
No
Ye s
No
Re-connect them properly.
Check for defective contact
points of the high voltage
system.
Replace the high voltage
power supply unit.
Inspection is
required.
122:Error
Low voltage FAN
error
Is the FAN of the low
voltage power supply
block working?
Is the FAN connector
connected correctly?
No
Ye s
No
Ye s
Check to make sure
connection of the FAN
connector.
Replace the low voltage
power supply unit.
Replace the FAN motor.
Replace the low voltage
power supply unit.
Inspection is
required.
123:Error
Abnormal
environment
humidity or
unconnected
humidity sensor
Does this error recur? Ye s
Cycle the power.
Replace the Environment
sensor board.
Inspection is
required.
124:Error
Abnormal
environment
humidity
Does this error recur? Ye s
Cycle the power.
Replace the Environment
sensor board.
Inspection is
required.
126:Error
Dew
condensation in
the printer was
detected.
This error tends to occur
after a printer is carried
in from the outsides.
Leave the printer for 2
hours to half a day at
room temperature, and
turn on the power. Does
this error recur?
Ye s
After leaving the printer at
room temperature, turn on the
power again.
Replace the Environment
sensor board.
Inspection is
required.
127:Error
Fuser FAN error Is the FAN connector
connected properly?
Does this error recur?
No
Ye s
Ye s
Re-connect it properly.
Replace the FAN motor.
Replace the CU/PU board.
Panel display Cause Check details Result Solution
Inspection is
required.
128:Error xx
PU FAN error
04 : Belt Cooling
Fan Error
05 : Fuser Side
Fan Error
08 : Image Drum
Motor Fan Error
0A : Fuser Intake
Fan Error
0C : Duplex Fan
Error
0D : Fuser
Exhaust Fan2
Error
Is the FAN connector
connected correctly?
No
Ye s
Check to make sure
connection of the FAN
connector.
Replace the FAN motor.
Inspection is
required.
131:Error
LED head
detection error
(131=Y, 132=M,
133=C, 134=K)
Inspection is
required.
132:Error
Inspection is
required.
133:Error
Inspection is
required.
134:Error
Inspection is
required.
142:Error
Cyan Image
drum position
detection error
Inspection is
required.
154:Error
The belt unit
fuse blown out.
Inspection is
required.
155:Error
The fuser unit
fuse blown out.
Inspection is
required.
160:Error
Toner sensor
detection error
(160=Y, 161=M,
162=C, 163=K)
This error does
not occur with
the factory
default settings.
Is the toner cartridge
installed?
Is the lock lever of the
toner set?
Does this error recur?
No
No
Ye s
Install the toner cartridge.
Move the lock lever of toner
cartridge to the lock position.
Replace the toner sensor
assembly.
Inspection is
required.
161:Error
Inspection is
required.
162:Error
Inspection is
required.
163:Error

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
