Oki MC873dn User Manual

Oki Data CONFIDENTIAL
45850101TH Rev.1
2-33
2. TROUBLESHOOTING PROCEDURES
Panel display Cause Check details Result Solution
Inspection is
required.
170:Error
Short circuit of
the heat roller
Thermistor was
detected.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
171:Error
Open circuit of
the heat roller
Thermistor was
detected.
Inspection is
required.
172:Error
Heat roller
thermistor
detected
the high-
temperature.
Does this error recur? Ye s
After leaving the printer, turn
on the power again.
Replace the fuser unit.
Inspection is
required.
173:Error
Heat roller
thermistor
detected the low-
temperature.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
174:Error
Short circuit of
the backup roller
Thermistor was
detected.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
175:Error
Open circuit of
the backup roller
Thermistor was
detected.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
176:Error
Backup roller
thermistor
detected
the high-
temperature.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
177:Error
Backup roller
thermistor
detected the low-
temperature.
Does this error recur? Ye s
Cycle the power.
Replace the fuser unit.
Inspection is
required.
181:Error
Duplex unit I/F
error Does this error recur? Ye s
Cycle the power.
Check to make sure the
contact points of the
connector and replace the
Duplex unit.
Panel display Cause Check details Result Solution
Inspection is
required.
182:Error
Tray2 I/F error
Does this error recur? Ye s
Cycle the power.
Check to make sure the
contact points of the
connector and replace the
Tray unit.
Inspection is
required.
183:Error
Tray3 I/F error
Inspection is
required.
184:Error
Tray4 I/F error
Power OFF/ON
190:Error
System memory
overflow
Cycle the power.
Power OFF/ON
203:Error
ssssssssssssssss
CU program
error
Record the figures on the
lower side of the LCD, and
cycle the power.
Power OFF/ON
204:Error
Cycle the power
Power OFF/ON
207:Error
CU program
error
Cycle the power
Power OFF/ON
208:Error
Power OFF/ON
209:Error
Custom Media
Type table
downloading
failed.
Cycle the power
Power OFF/ON
213:Error
CU program
error
Cycle the power
Power OFF/ON
214:Error
CU detected PU
program error
Cycle the power
Inspection is
required.
230:Error
Not detect RFID
Reader
RFID read device error
Does this error recur?
Ye s
Ye s
Check the FFC connecting
the RFID R/W board and the
CU/PU board.
Replace the CU/PU board
and the RFID R/W unit

Oki MC873dn Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9.5 s
Print speed (black, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 1200 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	35 cpm
Scan to	CIFS, E-mail, FTP, HTTP, Image, USB
Scan drivers	TWAIN
Scanner type	ADF scanner
Output color depth	24 bit
Scan speed (color)	50 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Color faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	1000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, EAP, SSL/TLS, WPA2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, , UPNP, Bonjour, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, WSD Scan, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, IPSEC, SecureProtocolServer, LDAP, LDAPS, CIFS, FTP, FTPS, SMTP, SMTPS, POP3
Internal memory	1260 MB
Internal storage capacity	250 GB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Paper input type	Paper tray
Total input capacity	300 sheets
Maximum input capacity	400 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, C4, C5, DL, Monarch
Custom media width	148.5 - 297 mm
Custom media length	210 - 431.8 mm
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 256 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, RJ-11, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1400 W
Power consumption (off)	0.1 W
Power consumption (sleep)	3 W
Power consumption (PowerSave)	30 W
Power consumption (average operating)	850 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	600 mm
Width	563 mm
Height	700 mm
