5238-E P-4
SECTION 1 PROGRAM CONFIGURATIONS
4. Program Format
4-1. Word Configuration
A word is defined as an address character followed by a group of numeric values, an expression, or
a variable name. If a word consists of an expression or a variable, the address character must be
followed by an equal sign "=".
Examples:
LE33013R0300300040001
• An address character is one of the alphabetic characters A through Z and defines the meaning
of the entry specified following it. In addition, an extended address character, consisting of two
alphabetic characters, may also be used.
• Refer to SECTION 13, 3-2. "Variables" for more information on variables.
4-2. Block Configuration
A group consisting of several words is called a block, and a block expresses a command. Blocks
are delimited by an end of block code.
• The end of block code differs depending on the selected code system, lSO or EIA:
ISO: "LF"
ElA: "CR"
• A block may contain up to 158 characters.
4-3. Program
A program consists of several blocks.
X-100 Z=100∗SIN[50] Z=V1+V2
Address Numerical
value
Address Formula Address Variable
Word Word Word
To Next Page
