5238-E P-5
SECTION 1 PROGRAM CONFIGURATIONS
4-4. Programmable Range of Address Characters
Address Function
Programmable Range
Remarks
Metric Inch
O Program name 0000 to 9999 same as left
Alphabetic
characters available
N Sequence name 0000 to 9999 same as left
G Preparatory function 0 to 999 same as left
X, Z
Coordinate values
(linear axis)
±99999.999 mm ±9999.9999 inch
C
Coordinate values
(rotary axis)
±359.999 deg. ±359.999 deg.
I, K
Coordinate values of
center of arc
Taper amount and
depth of cut in fixed
thread cutting cycle
Shift amount in
grooving cycle
±99999.999 mm ±9999.9999 inch
D, U, W, H, L
Automatic
programming
commands
0 to 99999.999 mm 0 to 9999.9999 inch
E ±99999.999 mm/rev ±9999.9999 inch/rev
A, B 0 to 99999.999 deg. 0 to 9999.9999 deg.
F
Feedrate per
revolution
0.001 to 99999.999
mm/rev
0.0001 to 999.9999
inch/rev
Feedrate per minute
0.001 to 99999.999
mm/min
0.0001 to 9999.9999
inch/min
Dwell time period 0.01 to 9999.99 sec same as left
T Tool number
6 digits
4 digits
same as left
6 digits (with nose R
compensation)
4 digits (without nose
R compensation)
S
SB
Spindle speed
M-tool speed
0 to 9999
0 to 9999
same as left
M
Miscellaneous
function
0 to 511 same as left
QA C-axis revolution 1 to 1999 (rev.) same as left
SA C-axis speed 0.001 to 20.000 min
-1
same as left
