Okuma OSP-P20L - Page 196

5238-E P-183
SECTION 8 LATHE AUTO-PROGRAMMING FUNCTION (LAP)
10-1-2. Tool Path and Program - Transverse Cutting
LE33013R0301000130001
AP starting point (Zs, Xs)
Tool change position (Zt, Xt)
(Za, Xa)
(Zb, Xb)
(Zc, Xc)
(Zd, Xd)
(Ze, Xe)
(Zf, Xf)
(Zg, Xg)
