SECTION 8 LATHE AUTO-PROGRAMMING FUNCTION (LAP)
• X-coordinate of the infeed line ≥ Bsp (X)
When cutting from finish contour start point Bsp along the finish contour, the cutting tool is
directly positioned at point Bsp (Z, X) at the rapid feedrate.
LE33013R0301000250002
AP starting point (Zs, Xs)
Blank material shape
Workpiece shape after the tool nose radius
compensation function has been activated
Cp1
Lc
Bsp
Xp
2
Xp1
