5238-E P-278
SECTION 12 USER TASK
Zero offset variables
LE33013R0301400140001
Set variables in the following manner: VZOFZ = 12364.256.
Zero shift variables
LE33013R0301400150001
Set variables in the following manner: VZSHZ = 50.
These zero shift variables deal with shift amount set by the zero shift operation called by G50, and
the set shift amount is cleared when the control is reset.
Tool offset variables
LE33013R0301400160001
Set variables in the following manner: VTOFZ [5] = 2.634.
This indicates that tool offset amount of the Z-axis for #5 is set 2.634.
Nose radius compensation variables
LE33013R0301400170001
Set variables in the following manner: VNSRZ [4] = 0.8
This indicates that the nose radius (on the Z-axis) of the tool assigned nose radius compensation
no. 4 is set to 0.8 mm.
VZOFZ
VZOFX
VZOFC
Zero OFfset of Z-axis
Zero OFf set Z-axis
Zero OFfset of X-axis
Zero OFfset of C-axis (for multi-machining model)
........
........
........
VZSHZ
VZSHX
VZSHC
Zero SHift of Z-axis
Zero SHift Z-axis
Zero SHift of X-axis
Zero SHift of C-axis (for multi-machining model)
........
........
........
VTOFZ [Tool Offset No.]
VTOFX [Tool Offset No.]
Tool OFfset of Z-axis
Tool OFfset Z-axis
Tool OFfset of X-axis
........
........
VNSRZ [Nose R Compensation No.]
VNSRX [Nose R Compensation No.]
NoSe Radius compensation of Z-axis
NoSe Radius Z-axis
NoSe Radius compensation of X-axis
........
........
