5238-E P-296
SECTION 12 USER TASK
Transmission data
LE33013R0301400380005
The result of the preceding program:
LE33013R0301400380006
Example 2. Output program (assuming printer is connected to CN0):
LE33013R0301400380007
The following will be printed when the program above is executed.
LE33013R0301400380008
A Compensation Yes/No = 1 Offset No. = 3 OX = 0.02 OZ = -0.31
1 5 10 15 20 25 30 40
(a) (b) (c) (d)
V1 = 1
V2 = 3
VTOFX [3] = 0.02
VTOFZ [3] = -0.31
N100 PUT ,4⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅4 spaces
N101 PUT ' ∗∗ '
N102 PUT ' TOOL OFFSET DATA'⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅Header
N103 PUT ' ∗∗ '
N104 PUT $0D0A⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅Carriage return code
N105 PUT ' N='
N106 PUT V1, 2⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅Tool offset number
N107 PUT ' X='
N108 PUT VTOFX[V1], 8⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅Tool offset value
N109 PUT ' Z='
N110 PUT VTOFX[V1], 8
N111 PUT $0D0A⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅Carriage return code
N112 WRITE 0
∗ ∗ ∗ ∗TOOL OFFSET DATA
N = 3 X = 5.412 Z = 14.339
