5238-E P-299
SECTION 12 USER TASK
Boolean Expressions
Functions
Operator Meaning Example Rule
OR Logical sum VDKN [11] OR VDIN [12]
Provide a space on either
side of the operator.
AND Logical product VDIN [11] AND VDIN [12]
EOR Exclusive OR VDIN [11] EOR VDIN [12]
NOT Negation
Function Meaning Example Rule and Remark
SIN Sine X = 15 * SIN [22.5] Numbers after function
operation symbols must be
enclosed in square
brackets.
When two elements are
specified within square
brackets, place a comma
between them.
The position of the decimal
point is determined in
accordance with the unit
system selected.
The unit systems for angle
commands are:
1 deg. for 1mm and 1 inch
unit system
0.001 deg. for 1m unit
system
0.0001 deg. for 0.0001 inch
system
COS Cosine Z = 15 * COS [22.5]
TAN Tangent Z = 15 * TAN [12.5]
ATAN
Arctangent (1)
Value range: -90 to 90
X = 15 * ATAN [22.5]
ATAN2
Arctangent (2)
Angle of point defined by
coordinate value (a, b).
Value range -180 to 180
ATAN2 [10.15]
SQRT Square root X = 15 * SQRT [224.5]
ABS Absolute value ABS [V15]
BIN Decimal to binary conversion
BIN [V15]
4BYTE
BCD Binary to decimal conversion
BCD [V20]
4BYTE
ROUND Rounding off fractions ROUND [V5]
FIX Cutting off fractions FIX [V7]
FUP
Counting fractions as a whole
number
FUP [V15]
DROUND
Rounding off fractions to three
decimal places (metric system) or
to four decimal places (inch
system)
DROUND [V20]
DFIX
Cutting off fractions below the
third decimal place (metric
system) or below the fourth
decimal place (inch system)
DFIX [V20]
DFUP
Count the figures below the third
decimal place (metric syst em) or
below the fourth decimal place
(inch system) as a whole number
DFUP [V21]
MOD
Remainder
(a - fix[a/b]*b)
MOD [a,b]
To Next Page
