SECTION 12 USER TASK
• Main Program
The cutting program is made up of three types of main program for each workpiece.
LE33013R0301400490004
LE33013R0301400490005
LE33013R0301400490006
O100
N101 Z400X800G00
N103 M02
N102 CALL O1000 V1=0101 V2=0202 V3=100 V4=120
LZ1=200 LZ2=150 LZ3=80
$ DX1=30 DX2=50
DX3=80 WLZ1=0.1 UDX1=0.2 XS=100 ZX=210
Workpiece A
$SHAFT-A. MIN %
O101
N101 Z400X800G00
N103 M02
N102 CALL O1000 V1=0303 V2=0404 V3=110 V4=130
LZ1=250 LZ2=170 LZ3=100
$ DX1=40 DX2=70
DX3=120 WLZ1=0.5 UDX1=0.25 XS=140 ZX=260
Workpiece B
$SHAFT-B. MIN %
O102
N101 Z400X800G00
N103 M02
N102 CALL O1000 V1=0505 V2=0606 V3=90 V4=150
LZ1=300 LZ2=200 LZ3=120
$ DX1=50 DX2=90
DX3=150 WLZ1=0.2 UDX1=0.3 XS=170 ZX=360
Workpiece C
$SHAFT-C. MIN %
