5238-E P-29
SECTION 3 MATH FUNCTIONS
[Supplement]
1) If I or K is omitted, I0 or K0 applies.
2) I and K values should be specified as radii.
3) An arc extending into two or more quadrants can be specified by the commands in a single
block.
4) If either X or Z is omitted, circular interpolation is possible within one quadrant.
5) An alarm will be activated if the difference in radius between the start and end point of an arc
is greater than the value set for optional parameter (OTHER FUNCTION 1) No. 6 Allowable
error in circular interpolation.
