5238-E P-85
SECTION 6 OFFSET FUNCTION
Original contour and associated program (program 1):
LE33013R0300800120001
Program 1:
LE33013R0300800120002
The original contour comprises: straight line - slope - straight line.
Program 2
The contour is the same as in program 1, but the cutting tool is relieved at point N3 in the +X
direction to change the spindle speed, then continuous cutting is intended.
LE33013R0300800120003
Program 2:
LE33013R0300800120004
In program 2, the cutting tool is positioned at a point where the tool nose R is in contact with line N3
- N31 at point N31 when the commands in block N31 are executed since the three designated points
X+
Z+
N4
N4
N3
N2
N1
N2
N3
N4
Z80
Z40
F0.2
Z20
N1 G42 G01 X100
X120
Z100 S1500
S1000
T010101 M03
S" code change
Uncut portion is left
N31
N4
Z+
N4
X+
N32
N3
N2
N1
N1
N2
N3
N31
N32
N4
G42
G00
G01
G01 X100
X120
X124
X120
Z100
Z80
Z40
Z20
F0.2 S1500
S1000
T010101 M03
