Maintenance
8-4 OPERATION GUIDE
Cleaning the Transfer Rollers
1
Open the front cover.
2
Remove the cleaning brush.
3
Grasp the Left Cover handles to
lift the cover and open it.
4
Turn the Left Transport Roller
gear as shown in the illustration
and move the brush from left to
right while turning the gear to
remove any dust or dirt on the
rollers.
5
Close the left cover.
To Next Page
