Name of Parts
1-6 OPERATION GUIDE
Message Display
The message display on the operation panel shows:
• Status information, the messages listed below which are displayed
during normal operation.
• Error codes, when the printer requires the operator’s attention, refer to
If one of the following indications is Displayed on page 9-5.
Status Information
Error codes
Refer to If one of the following indications is Displayed on page 9-5.
System Menu (the mode after warm-up processing has been completed or
[Reset] pressed)
The copier has been set at the factory to automatically select a
magnification ratio of 1:1 for the same size of paper as the original in the
Auto Mode with the No. of Copies at “1” and for the Image Quality.
NOTE: The Default Settings can be changed in the System Menu.
In the case where an optional cassette is present, the cassette selected in
the System Menu can be changed. (Refer to Selected Cassette on page
5-14.)
The Image Quality Mode selected in the System Menu can be changed.
(Refer to Original Image Quality on page 5-9.)
The Default Setting for the copy density can be changed to the Auto.
(Refer to Initial Density on page 5-9.)
Auto Clear function
After the copy has been produced and a fixed interval (10 to 270 seconds)
has elapsed, the copier will automatically revert to the state it was in when
warm-up processing was completed.(However, the copy density mode and
the Image Quality will not revert back to their original state. Copies can still
be repeatedly produced with the same Copy Mode, No. of Copies, copy
density and other settings if the Auto clear function has not been activated.
Message Meaning
Self test The copier is performing self-diagnostics after power-up.
Please wait. The copier is warming up and is not ready.
When the copier is switched on for the first time, this message will take
approximately 20 seconds.
Ready to copy. The copier is ready to copy.
To Next Page
