Olympus 38DL PLUS Basic Operation Manual

DMTA-10009-01EN [U8778346], Rev. D, November 2016
Chapter 4 58
4.5.2 Adjusting the Delay Value
The delay of the waveform display adjusts the beginning of the horizontal span. You
can adjust the delay to display the waveform of interest in the center of the waveform
display. This function is very useful when using delay line or immersion transducers,
or when measuring thick material so that the measured echoes can be seen in greater
detail.
To adjust the delay value
1. Press [2nd F], [RANGE] (DELAY).
2. Use the arrow keys to adjust the delay value.
3. Press [2nd F], [RANGE] (DELAY) again to stop editing the delay value.
Press and hold the [RANGE] key to reset the delay to zero.
4.5.3 Activating the Zoom Function
The zoom function automatically and dynamically sets the delay and the range values
to optimally track and show the detected echo in the waveform display.
To activate the zoom function
1. From the measurement screen, press [ZOOM].
The zoom flag ( ) appears on the right side of the waveform display, below the
power indicator.
2. Press [ZOOM] again to turn off the zoom function.
The resulting zoomed waveform depends on the current measurement mode. The
zoom for D79X dual element transducers and mode 1 single element transducers
centers the first back-wall echo on the screen (see Figure 4-8 on page 59).
TIP

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
