Olympus 38DL PLUS Basic Operation Manual

DMTA-10009-01EN [U8778346], Rev. D, November 2016
Appendix 88
Minimum and maximum
thickness
Single element: 0.1 mm to 635.0 mm (0.004 in. to 25 in.)
Dual element: 0.5 mm to 635.0 mm (0.020 in. to 25 in.)
Table 5 Display EN15317 specifications
Parameter Va lu e
Type Color graphical TFT, LCD, 640 × 480 pixels
Size [Height] × [Width], [Diagonal]
56.16 mm × 74.88 mm, 93.6 mm
(2.21 in. × 2.94 in., 3.68 in)
Table 6 Transmitter EN15317 specifications
Parameter Va lu e
Transmitter pulse Adjustable square wave pulser
Pulser voltage Pulse voltages: 60 V, 110 V, 150 V, and 200 V
Pulse rise time Damping in: 5 ns typical
Damping out: 3.5 ns typical (pulse width dependent)
Pulse duration Adjustable to probe frequency
Table 7 Receiver EN15317 specifications
Parameter Va lu e
Gain control Automatic or manual: 0 dB to 99 dB
Frequency range 0.5 MHz to 24 MHz typical (filter dependent)
Table 8 Other EN15317 specifications
Parameter Va lu e
Data storage Internal and external 2 GB microSD memory cards.
Each card:
475000 thickness readings or
20000 waveforms with thickness readings
Table 4 General EN15317 specifications (continued)
Parameter Value

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
