Chapter 5 Functions
103
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Figure 5.52
2. Move the arrow pointer using the domepoint on the keyboard.
3. To delete the arrow pointer, press the “Shift” and any arrow key.
• The arrow pointer disappears when the endoscopic image
screen once changes to the other menu and returns to the
endoscopic image screen.
• The arrow pointer can also be displayed and cleared from the
scope switches and/or foot switches. For how to set up the
scope switches and foot switches, see “Remote switch and
foot switch (EXERA and VISERA)” on page 219.
ABC123
Mike Johnson
M 51
03/03/1954
12/12/2005
12:12:12
John Smith
Cardiac end of the stomach
Arrow pointer
Appears at the center of
the endoscopic image.
