194
Chapter 9 Function setup
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
9.2 System setup
Basic operation of the system setup
1.
Press the “Shift” and “F1” keys together (see Figure 9.2). The “System
setup” menu appears on the monitor (see Figure 9.3).
Figure 9.2
Figure 9.3
2. Click “System”, “Printer”, etc., on the left side of the menu. The applicable
setting items appear on the right side of the window.
3. Click the desired text box to place the cursor and enter the data.
Buttons Functions
OK Determines the entered data. Used to move back to the endoscopic
image.
Back Cancels the entered data. Used to move back to the endoscopic image.
Table 9.2
F1
Shift
