Chapter 5 Functions
137
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
2. Click the buttons with the arrow pointer to operate the menu.
3. Click “Back” to return to the endoscopic image.
Entering new patient data
1.
Press the “Shift” and “F3” keys together to display “Patient Data” menu (see
Figure 5.85).
Figure 5.85
2. Click “No data” in the patient name list (see Figure 5.85).
Button Function
Clear Clears all previously registered patient data.
Save Saves the registered 40 patient data on the PC card.
Load Loads the 40 patient data from the PC card onto the video system center.
Back Closes the patient menu and returns to the endoscopic image.
Call Returns to the endoscopic live image and displays the patient data
selected.
Edit Opens the patient data input screen.
Delete Deletes selected patient data.
Table 5.17
