Chapter 2 Nomenclature and Functions
27
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
2.4 Side panels
2.5 Videoscope cable EXERA II (MAJ-1430)
Front side
Rear side
Ventilation grills
Ventilation grills
Scope side connector
Connect to the scope
connector of the endoscope.
“UP” mark
Video plug
Connect to the video
system center “UP”
side up.
Connect to the video
connector socket of the
video system center.
