Chapter 9 Function setup
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Color mode
This menu sets the color tone of the monitor from four modes. The color mode
can be changed during observation. See “Color mode (“Shift” + “Alt” + “1”, “2”,
“3”, “4”)” on page 104 The setting of “Color Mode” is valid only to “Scopes B”,
“Scopes C” and “Scopes D” in Table 9.33 on page 233.
The color mode in this menu is not valid for NBI observation, because NBI
observation uses the exclusive color mode for each endoscope.
Figure 9.22
1. Click “Enhancement” on the system setup menu. The setting items appear
on the right side of the window (see Figure 9.22).
2. Click “ ” of “Color mode” (see Figure 9.22). The color modes appear in the
pull-down menu.
3. Click the desired color mode. The selected mode is displayed.
Setting value Explanation
Mode 1 Same as the color mode 1 of VISERA video system center OTV-S7V
Mode 2 Less reddish color than the Mode 1
Mode 3 More yellowish color than the Mode1
Mode 4 Standard color mode
Table 9.28
