Chapter 9 Function setup
253
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
6. Click “Back” to return to the user name list.
7. To reset the settings of other registered users, repeat steps 2. to 6.
8. Click “Back” to return to the endoscopic image.
Deleting user preset data
This operation deletes the user preset data with the user name.
1. Press the “Shift” and “F2” keys together (see Figure 9.50). The user name
list of the user preset menu appears on the monitor (see Figure 9.51).
Figure 9.50
Figure 9.51
2. Click the user name in the user name dialog box to be deleted. The user
name is highlighted.
3. Click “Delete” to delete the user preset data. A confirmation message
appears on the monitor.
To Next Page
