130
Chapter 5 Functions
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Figure 5.79
• When the VCR is connected using the VTR remote cable
(MH-992), only the recording and pause operations can be
operated.
• When “DVD (IEEE1394) of the VCR type is selected, only the
recording and pause operations can be operated
(“Videocassette recorder” on page 211).
• The fast forward and rewind operations can be operated only
when the VCR is set to RS-232C and IEEE1394.
• The “VCR” does not appear when the patient data are
cleared from the monitor.
• Also refer to the instruction manual for the VCR.
• The recording and pause operations can also be controlled
from the scope switches and/or foot switches. For how to set
up the scope switches and foot switches, see “Remote switch
and foot switch (EXERA and VISERA)” on page 219.
