Chapter 4 Operation
49
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Summary of connection
This diagram gives an overview of all connections. For further details of the
connection, refer to the instruction manuals of the ancillary equipment being
used.
Figure 4.4
Light source
VISERA series
Fiberscopes
Rigidscope
Light guide cable
Video adapters, camera heads, etc.
Videoscope cable EXERA II
CV-180
The numbers show the order of connection.
2
2
2
3
3
4
EVIS series and
ultrasonic videoscope
2
3
Camera head
Video adapter
1
1
1
1
