58
Chapter 4 Operation
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
3. Enter data.
Figure 4.12
4. When modifying data, press the arrow key to move the cursor to the input
position and edit the data.
5. When deleting all patient data displayed on the monitor, press the “EXAM
END” key on the keyboard (see Figure 4.13).
Figure 4.13
Data data input condition Entry example
ID No. Up to 15 characters ABC123
Name Up to 20 characters Mike Johnson
Sex 1 character M
Age Up to 3 characters. Automatically calculated after entering D.O.B. 51
D.O.B. 8 characters. Enter the numbers according to the format (see
page 197).
03031954
Physician Up to 20 characters John Smith
Comment Up to 37 characters Cardiac end of the stomach
Table 4.5
