◆ CV-190/190PLUS/290+EU-ME1 type E1S2/2
105
[SETTING INFORMATION]
Setting
model
Step Default
Setting
parameter
CV-1500
Setting > System setup > Video output > 12G-SDI OUT
(4K/HD) signal
HD:1080p 4K
Setting > System setup > Peripherals 1 > Keyboard type MAJ-1923
US MAJ
-
1710/
1995 (EN)
Setting > System setup > Peripherals 2 > Select PIP/POP
device
CV CV
Setting > System setup > Peripherals 2 > Ultrasound center
type
Not connected
EU-ME1/
EU-ME2
Setting > System setup > Peripherals 2
>CV PIP/POP US input terminal
HD/SD input
(SDI)
HD/SD input
(SDI)
Setting > System setup > Peripherals 2
> US/multi-monitor Fixed EVIS output
Disabled Enabled
Setting > System setup > Peripherals 2 > 12G-SDI OUT
(4K/HD)
Fixed EVIS Fixed EVIS
Setting > System setup > Peripherals 2 > 3G-
SDI OUT (HD)
EVIS/US switch
EVIS/US switch
Settings > User Presets > New entry or Edit > Release/Pre-
freeze
> Record ext. source
ON OFF
Setting > Users Presets > New entry or edit > PIP/POP >
Display method
PIP PIP
Setting > Users Presets > New entry or edit > PIP/POP
> PIP position
Lower left Lower left
Setting > Users Presets > New entry or edit > PIP/POP
> Select CV ext. source
HD/SD input
(SDI)
HD/SD input
(SDI)
EU-ME1
System setup > Remote > Remote > EVIS
Video system
Center 2
Video system
Center 2
Setting > Display > Video signal format SDTV(RGB) HDTV
Setting > Display > Aspect 4:3 4:3
OEV321UH
MENU > Preset > Load Preset B/C B/C
MENU > Input/Output Configuration > Port A Input Select 12G-SDI 1 12G-SDI 1
OEV262H
Preset > Load preset B/C B/C
PORT A SDI1 SDI1
* Please refer to CV-190/190PLUS/290 for the setting of connection with CV-190/190PLUS/290.
