Olympus EVIS X1 - CV Remote LINK-IN; Not Connected UPD-3

89
◆ CV-190/190PLUS/290+UPD-3+PSCU 2/2
■ Supplement
・ When LINK connected , UPD-3's front-panel control is overridden, and the operation is performed from the
CV-touch panel.
・ Please refer to the External Image Record Setting for how to record UPD-3/PSCU images.
■ Reference
・ Since the PIP has been entered into the CV, UPD-3/PSCU screen is displayed on the monitor by performing
the following operations:
[How to display UPD-3/PSCU screen]. Home > Function List > Info. > PIP/POP > PIP ON
・ It is able to switch UPD-3 or PSCU image by using PIP input select button.
Setting
model
Step Default After change
CV-1500
Setting > System setup > Video output > 12G-SDI OUT
(4K/HD) signal
HD:1080p 4K
Setting> System setup > Peripherals 2> Select PIP/POP device CV CV
Setting> System setup > Peripherals 2 > UPD ScopeGuide
Type
Not connected UPD-3
<Display UPD-3 image>
Settings > User Settings > PIP/POP > Select CV ext. source
HD/SD IN
(SDI)
HD/SD IN
(SDI)
<Display PSCU image>
Settings > User Settings > PIP/POP > Select CV ext. source
HD/SD IN
(SDI)
Y/C IN
UPD-3 Menu > System settings > System > Remote > Connection CV remote LINK-IN
