■ Preparation for connection
Connecting CV-1500 to CV-190/190PLUS/290 requires the following cable
types:
■ Operational constraints
◆ Turn both CV-190/190PLUS/290 and CV-1500 on when using the 180/260 system scope.
◆ When removing the 180/260 system scope, be sure to turn off CV-190/190PLUS/290 and
remove the scope.
◆ When CV-190/190PLUS/290 is turned off, the error "E532 (image cable not connected")
will occur, but the error will be resolved by turning on the power supply again. (Not a
defect.)
◆ The display position of the PIP screen is limited to the lower left display regardless the
user setting.
◆ Do not operate from CV-190/190PLUS/290 front panel. Operate from CV-1500 touch
panel. It may cause errors such as "white balance cannot be completed" and "CV-
190/190PLUS/290 error display" etc. (If it occurs, restart both CVs.)
◆ The water container should be placed on the holder of the trolley.
73
# Product symbol Name
Numb
ers
1
MAJ-2477
Sets of EXERA III/LUCERA ELITE
connections
1
Set
Breakdown
MAJ-2363
CV interface converter 2
1
MAJ-1918
Peripheral Device Remote Cable (1.8M)
3
MAK
-
2432
Activation connectors
1
MAJ-1433
Foothold
1
2
MAJ-1951
SDI
-cable (2.5M)
1
MAJ-1912
SDI
-cable (8.5M)
3
MH-985
Y/C video cable (2.95M)
1
MAJ-987
Y/C cable (15M)
4 MAJ-1941
Light source cable
1
※ Use CV communicatin converter 2 (MAJ-2363) when connecting with CV-190/190PLUS/290.
It is required.
Conventional MAJ-1916 cannot be used.
When using 180/260 series scope 3/3
