Olympus EVIS X1 - CV-190;190 Plus;290; Y;C Cable

75
◆ CV-190/190PLUS/290
<List of Cables>
CV
Adaptor
CV-190/290
KEYBOARD
terminal
CV-190/290
ADAPTER
terminal
CV-LINK
terminal
Light source
device terminal 1
Light source
device terminal
2
Keyboard
Terminals
Adapter
Terminals
CV-1500
CV-190/190PLUS/290
MAJ-2363
2
CV input (SDI).
SDI output 1
S-Video Out
CV inputs (Y/C
♯
Product
symbol
Name
1
MAJ-1951 SDI cable 2.5M
MAJ-1912 SDI cable (8.5M)
2
MAJ-985 Y/C video cable 2.95M
MAJ-987 Y/C cable 15M
3
MAJ-1941 Light source cable
4 MAJ1918 Device Remote Cables 1.8M
★MAJ-2432
1
3
4
Setting
model
Step Default After change
CV-1500
Setting> System setup > Peripherals 1>CV interface converter
type
Not
connected
MAJ-2363
Setting > System setup > Pripherals 1 > Ext. video processor
type
Not
connected
CV-190/190PLUS
CV-290
[SETTING INFORMATION]
4
4
