Olympus EVIS X1 - EU-ME1 Setting Type (One Monitor)

Type
A B
CV PinP(SDI IN) CV PinP(Y/C IN)
US image
Monitor display EVIS Imaging Comparable (4K, HD, SD)
Save image quality
Selectable in the setting
*Same as EVIS images
SD image quality only
Simple diagram
Remarks
Wiring Need an SDI converter Simple
P in P - -
Maneuverability - -
Stored image Options* Options*
Outline of EU-ME1 setting type (using one monitor)
55
The outline of each connection type is as follows
*Setting allows you to select images to be stored during PIP display ON.
(【10. Appendix) Reference)
Recomme
ndation
Recomme
ndation
Keyboard Keyboard
Remote
Remote
SDI
Converter
