Olympus EVIS X1 - [Setting Information]

◆ CV-190/190PLUS/290+EU-ME1 type B 2/2
99
[SETTING INFORMATION]
Setting
model
Step Default
Setting
parameter
CV-1500
Setting > System setup > Video output > 12G-SDI OUT
(4K/HD) signal
HD:1080p 4K
Setting > System setup > Peripherals 1 > Keyboard type MAJ-1923
US MAJ
-
1710/
1995 (EN)
Setting > System setup > Peripherals 2 > Select PIP/POP
device
CV CV
Setting > System setup > Peripherals 2 > Ultrasound center
type
Not
connected
EU-ME1/
EU-ME2
Setting > System setup > Peripherals 2
>CV PIP/POP US input terminal
HD/SD input
(SDI)
Y/C input
Setting > System setup > Peripherals 2
> US/multi-monitor Fixed EVIS output
Disabled Disabled
Settings > User Presets > New entry or Edit > Release/Pre-
freeze
> Record ext. source
ON OFF
Setting > Users Presets > New entry or edit > PIP/POP >
Display method
PIP PIP
Setting > Users Presets > New entry or edit > PIP/POP
> PIP position
Lower left Lower left
Setting > Users Presets > New entry or edit > PIP/POP
> Select CV ext. source
HD/SD input
(SDI)
Y/C input
EU-ME1 System setup > Remote > Remote > EVIS
Video system
Center 2
Video system
Center 2
OEV321UH
MENU > Preset > Load Preset B/C B/C
MENU > Input/Output Configuration > Port A Input Select 12G-SDI 1 12G-SDI 1
* Please refer to CV-190/190PLUS/290 for the setting of connection with CV-190/190PLUS/290.
