◆ UPD-3+PSCU 2/2
■ Supplement
・ When LINK connected , UPD-3's front-panel control is overridden, and the operation is performed from the
CV-touch panel.
・ Please refer to the External Image Record Setting for how to record UPD-3/PSCU images.
■ Reference
・ Since the PIP has been entered into the CV, UPD-3/PSCU screen is displayed on the monitor by performing
the following operations:
[How to display UPD-3/PSCU screen]. Home > Function List > Info. > PIP/POP > PIP ON
・ It is able to switch UPD-3 or PSCU image by using PIP input select button.
