When using 180/260 series scope 1/3
It is necessary to connect CV-1500 to CV-190/190PLUS/290.
* The scope before the 260-180 series cannot be used.
* When using the 290-190 series, there is no need to connect CV-190/190PLUS/CV-290.
■ Pre-setup checks
◆ Ensure that CV-190/190PLUS/290's patient-information display settings are set to
"Compatible Modes".
If the compatibility mode is not set, set the compatibility mode before connecting with CV-
1500. When connecting without setting, the error "E301" will occur.
* The patient information display setting can be changed only by Olympus service
personnel.
Please check by the following methods and contact service personnel prior to the
establishment of CV-1500 if setting is required.
[Confirmation method]
It can be determined whether the cursors can be moved to the image yellow frame, when the
patient information is entered.
Compatible mode: The cursors can move to the part indicated in the yellow box
(letter can be input)
Not in compatible mode: The cursors cannot be moved to the part indicated in the
yellow box (letter input not possible)
71
Not in compatibility modeCompatibility mode
CV-190/190PLUS/290 screen
