When using 180/260 series scope 2/3
■ Precautions for placement
◆ Check if CV-190/190PLUS/290 is "end of Exam" prior to connecting.
◆ Install CV-1500 on CV-190/190PLUS/290 to make the touch panel easier to operate.
◆ When CV-190/190PLUS/290 is connected, CV-190/190PLUS/290 sets are automatically
changed. If it is necessary, note the setting beforehand.
◆ If it is placed in WM-NP2, the height of the top shelf needs to be changed
(NP3 does not need to be changed.)
72
*If set up in oppsite way, the scope cable prevents the touch panel from operating.
[When placing on a WM-NP2].
When positioning the top row so that six
holes are visible above the shelf plate, it
can be placed as in the right panel.
1
3
2
4
5
6
