42
◆ UCR
<List of Cables>
#
Product
symbol
Name
MAJ-2047 UCR Communication cable (2.5M)
MAJ-2048 UCR Communication cable (8.5M)
Setting
model
Step Default
Setting
parameter
CV-1500
Setting > System setup > Peripheral 1>CO2 Regulation Unit type
Not
connected
UCR
Setting > User setting > new entry or edit > Equipment settings > Supply
type
Air CO2
Setting > user setting > new entry or edit > Equipment settings > Air flow
level
High Optional
Setting > user setting > new entry or edit > Remote Switch / Customized
key
-
Air supply/Air
supply
CO2
insufflation
■ Reference
Assign the operating function to the Remote Switch and Custom Button as option
You can operate from the touch panel of CV-1500 without assigning a function to the Remote Switch
Custom Button.
[Operation from touch panel]. Home > Function List > Pump/Peripheral > Supply type > CO2 flow
UCR
CV-1500
[SETTING INFORMATION]
