1. System organization
This document explains the installation, wiring, setting, and precautions for
delivery and installation using the following system configuration.
Monitor
・ OEV321UH
・ OEV262H
・ OEV261H
US Center
・ EU-ME1
・ EU-ME2
CV-1500
UPD-3
UCR
Video recorder
・ IMH-200
・ IMH-20
・ IMH-10
・ nCare *
Trolley
・ WM-NP2
・ WM-NP3
OFP-2
Printer
・ OEP-4
・ OEP-5
・ OEP-6
Video system
center
・ CV-190
・ CV-190PLUS
・ CV-290
PSCU
*Touch panel monitor is required to operate nCare.
