19
IX73
f
4
i
d
h
e
i
g
e
IX3-HO35D
Place the 35 mm dish
d
on the 35 mm dish fixing holder
e
.
Tighten the fixing screws
f
(3 screws) placed on the side with the
Allen screwdriver provided with IX3-HO35D to secure the 35 mm
dish.
} The 35 mm dish can be secured easily by tightening the fixing
screws after flipping over the 35 mm dish in advance.
Do not tighten the fixing screws too firmly. The dish may be
damaged.
Set the fixing holder
e
in the center of IX3-HO35D
g
so that the
cut-out meets the holder fixing knob
i
.
Loosen the holder fixing knobs
i
.
Rotate the fixing holder
e
clockwise to push it to the rotation stop-
per
h
.
Tighten the holder fixing knobs
i
.
} The 35 mm dish fixing holder
e
can be sterilized by using the
autoclave.
<<35 mm Glass Bottom Dish Recommended>>
• Matsunami Glass D111310
• MatTek P35GC-1.5-14-C
<<35 mm Dish Recommended>>
• BD Falcon 351008
1
CAUTION
2
3
4
5
