20
With the mechanical stage IX-MVR + stage IX2-SP
} 96-well or 24-well microplates, etc. are held in place by the speci-
men holder.
Microplates with dimensions of max. 136 mm x 92 mm can be ac-
commodated in this way.
Open the spring-loaded finger of the specimen holder 1 and slide
the microplate into the holder frame. Gently release the curved
finger to clamp.
} To secure other vessels than microplates, various optional hold-
ers are available. A Terasaki plate holder is available for holding
Terasaki plates (72-well, 60-well). When using this, it is necessary to
replace the stage scales with those provided with the plate holder.
Dish holders are available for 35 mm, 54 mm and 65 mm diameter
dishes, a slide glass holder is available for holding slide glass, and
the IX2-BCTP* is available for a blood cell test plate holder.
* A blood cell test plate or other calculating chamber for bacteria
and eosinophil with mounting section dimensions corresponding
to H 77 x V 35 x D 2 mm can be used. A 60 mm diameter dish can
also be used.
1
1
