Omnia Omnia.9 Installation And Operation Manual

92

Specifications
Preliminaryspecificationsatthetimethismanualwasprintedareprovidedhere.
FrequencyResponse
 +/0.5dB20Hzto15kHz;17.5kHzinextendedmode.
SignaltoNoiseRatio
 Greaterthan80dBudeemphasized,20Hzto15kHz.
SystemDistortion
 Lessthan0.01%THDbelowpreemphasis;inaudibleabove.
StereoSeparation
 65dBminimum,20Hzto15kHz;70dBtypical.
DigitalOutputLevel
 Adjustablefrom24dbFSto0.0DBFSin0.1dBincrements.
StereoBasebandOutput
 Adjustablefrom24.0dBFSto0.0dBFSin0.1dBincrements.
A/DConversion
 CrystalSemiconductorC55361,24bit128xoversampled.
 Deltasigmaconverterwithlinearphaseandantialiasingfilter.
 PreADCantialiasfilterwithhighpassfilterat<10Hz
D/AConversion
 CrystalSemiconductorCS4391,24bit,128xoversampled.
 Externalsyncinput
 PerAES11DigitalAudioReferenceSignal(DARS),referencefordigitaloutputsamplerate.
ExternalSyncRange
 44.1or48kHz.
Inputs/Outputs
 Balanced,EMIfiltered,L/Ranaloginputandoutputconnectors.
 AESReferenceInput,MainDigitalInput,AuxDigitalInput,MainFMOutput1,MainFM
Output2,andAuxOutputonXLRconnectors,includingrecognitionofexternalsyncsignal
onAESReferenceInput.MainandAuxilliarydigitalinputsacceptsampleratesbetween
32kHz–96kHzandhavesignalrateconverters.
 SharedEthernet/LivewireRJ45portsupporting100and1000BASETEthernet.
PowerRequirements
 100264VAC,4763Hz,autosensing.
