TheHomeMenu
Omnia.9’sHomeMenuisthehighestlevelmenuavailableintheuserinterface.Fromhere,youcan
configureandrouteInputsourceaudio,accesstheUndomenusandcontrols,accessthecontrolsof
thevariousprocessingcores,configuretheMonitorOutputs,andaccesssystemsettingsincluding
InputandOutputoptions.
SystemMenu
The System Menu contains submenus for System Status, I/O Options, Omnia.9’s builtin File
Recorder,TimeandDatesettings,andSystemConfiguration.
SystemStatusMenu
TheSystemStatusmenuisdividedintotwosections–SystemInformationandAudioI/OStatus.
TheSystemInformationportionshowsinformationaboutOmnia.9’soperation,includingCPUload,
Software and GUI version, and the Host Name, IP Address, and MAC address of your unit.   The
Audio I/O Status section shows the current system sample rate as well as detailed information
aboutaudioinputandoutputconfigurations.
I/OOptionsMenu
The I/O Options menu has three submenus – Input Options, Output Options, and MPX Output
OptionsthatallowyoutodecidewhichofOmnia.9’sphysicalinputsgetroutedtothethreeinternal
audioinputs,andinturn,whichofthosethreeaudiopathsfeedthevariousprocessingcores.
 TheInputOptionsmenuiswhereyouchoosewhichphysicalrearpanelinput(Analog,Main
Digital,AES Reference,Aux Digital)feedseachof Omnia.9’sthree audioinput paths.You
mayalsoselectasecondaryinputsourcetobeusedintheeventyouloseaudiofromthe
primarysource.

 Oncethosepathsareestablished,youcanchoosewhichofthosethreeinputsfeedeachof
theprocessingcores.Dependingupon configuration,thisincludesFM,HD1, HD2,HD3,
threestreams,andtheStudioProcessingcore.

 TheOutputOptionsmenuprovidesAES/EBUaudiooutputoptionsincludingFMPre
emphasizedL/R,FMDeemphasizedL/R,HD1,HD2,HD3,HeadphoneOut,andSpeaker
Out.(Note:
FM De-emphasized L/R is suitable for monitoring only. Feeding to a stereo
generator which provides pre-emphasis will work, but it WILL cause overshoots and you
WILL lose loudness. The Omnia.9 should be the ONLY device providing the FM Pre-
Emphasis. Any pre-emphasis in the FM Exciter/Transmitter should be defeated).

 TheMPXOutputOptionsmenuiswhereyouwillfindthecontrolsfortheOmnia.9’sbuiltin
MPX stereo generator, including those for the MPX1 and MPX2 Output Levels, output
routingoptionsfortherearpanelMPX1andMPX2inputs,theFMDiversityDelaycontrol,
