UnderstandingtheUserInterfaceandDisplay
Omnia.9’sUserInterface(UI)issetupin“layers”or“tiers.”
Thefirsttieralwayscontainsthehighestlevel(mostgeneral)menuoptionsintheformofbuttons.
Whenselected,thesebuttonstakeyoutoasecondtierofmenu options,whicharealsobuttons,
butofamorespecificnature.ThethirdtierismadeupofOmnia.9’scontrols.
NonExpertNavigationMode
Bydefault,Omnia.9powersupinthe“NonExpert”navigationmode.

Inthismode:
 Thetopportionofthescreenisdevotedtothedisplaywindows.
 Thebottomportionofthescreenshowsthebuttonsorcontrolsforthecurrenttier.
 In between these two areas is a navigation bar that shows you exactly where you “are”
withinOmnia.9,alongwithnavigationarrowbuttonsthatletyougoforwardorbackwardto
mostplacesyouhavevisitedinthefourthtier.
 Selectingandholdingdowneitherofthearrowbuttonswillbringupalistoftheseplacesso
youcanrevisitthemdirectly.
 Doubletappingonanyofthecontrolsbringsupamagnifiedviewthathastwolargesliders
–onefora“course”adjustmentandonefora“fine”adjustment.Onceyou’vemadeyour
adjustments, tap “Done” to return to the previous display of all the controls for the tier
you’rein.


Tier1
Tier2
Tier3
Tier3
Controls
Navigation
Arrows
