33

TheMultibandStereoEnhancermeterswillbedisplayedifthecurrentpresetemploysthisfeature.
Dependinguponhowthe displaywindowhas been reconfiguredand resized,thesemetersmay
appearineitheraverticalorhorizontalconfiguration.
 Intheverticalconfiguration,yellowbarsextendingfromthemiddleofthedisplayoutward
towardthetopandbottomshowawideningofthestereoimageineachband.Redbars
extendingfromthetopandbottomtowardthemiddleindicateanarrowingofthestereo
image.








 Inthehorizontalconfiguration,yellowbarsextendingfromthemiddleoutwardtowardthe
leftand right of thedisplayindicate awideningof the stereoimage. Redbars extending
fromtheleftandrightedgestowardthemiddleindicateanarrowingofthestereoimage.












Increasing
Stereo
Image
Decreasing
Stereo
Image
IncreasingStereoImage
DecreasingStereoImage
