Omron CK3M Series User Manual


ProjectLoadErr
Register name Sys.ProjectLoadErr
Description User Project File Read Error
Range 0 to 1
Details 0: No error
1: User Project File Read Error
Detection timing When power is turned ON or reset
Recovery Cycle the power supply, reset command ($$$), downloading
Effects Operate at default settings.
Cause and cor-
rection
Cause (Assumed cause) Correction Prevention
The project file is corrupted. After executing the re-initi-
alization command ($$
$***), download the project
file again.
If the unit power supply is
turned OFF while saving
the project file, the project
file may be corrupted.
Do not turn OFF the power
supply while saving.
An illegal project file was
downloaded.
Identify the cause from the
output window
, and make
corrections to the project
file. After the corrections,
execute the re-initialization
command ($$$***), and
download the project file
again.
None
CPU Unit failure If this error persists even
after you make the above
corrections, replace the
CPU Unit.
None
Precautions/
Remarks
None

PwrOnFault
To ensure that the errors when the power is turned on or during reset can be checked with 1 bit, the
Sys.PwrOnFault register is set to "1" when any of Sys.FileConfigErr, Sys.HWChangeErr, Sys.Con-
figLoadErr, or Sys.ProjectLoadErr is "1".
6 Troubleshooting
6-17
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
6-4 Sys.Status Register
6
6-4-2 Details of Flags
