E5CK
5–45
Event input assignment 1
Conditions of Use
The event input function must be in use.
Ă• The following functions are assigned as event inputs:
Run/reset," Auto/manual," Hold/hold cancel," Advance," Pattern select 0 to 1"
Ă• Weighting of the remote/local function is as follows:
Pattern select 0 = 2
0
, Pattern select 1 = 2
2
Ă• When event input is used as advance input, program steps are advanced at the rising
edge (OFF!ON) of the event input signal. When event input is used as run/reset inĆ
put, the program is reset at the rising edge (OFF!ON) of the event input signal, and
the program runs at the falling edge (ON!OFF). Other signals are accepted as durĆ
ing regular operation.
Settings Function
Event input disabled
OFF³ON : Reset /ON³OFF : Run
ON : Manual /OFF : Auto
ON : Hold /OFF : Hold cancel
OFF³ON Execution
OFF: pattern 0 / ON: pattern 1 (*1)
OFF: pattern 0 / ON: pattern 2 (*2)
*1 Enabled when the number of patterns" parameter is set to 2" or more
*2 Enabled when the number of patterns" parameter is set to 3" or more
Ă• Default is
".
ĂRelated description
4.7 How to Use Event input (page 4Ć23)
ĂRelated parameters
Remote/local" (level 2 mode)
Hold" Advance" (level 0 mode)
Pattern No." (level 0/program mode)
ĂOption units
E53ĆCKB
Option Mode
Function
Setting
See
Model
