CHAPTER 5 PARAMETERS
E5CK
5–1
CHAPTER 5
PARAMETERS
This chapter describes the parameters of the E5CKĆT.
Use this chapter as a reference guide.
CHAPTER5
Conventions Used in this Chapter 5Ć2. . . . . . . . . . . .
Protect Mode 5Ć3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Mode 5Ć5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Level 0 Mode 5Ć6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Program Mode 5Ć11. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Level 1 Mode 5Ć17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Level 2 Mode 5Ć24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup Mode 5Ć28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Expansion Mode 5Ć36. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Option Mode 5Ć44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Calibration Mode 5Ć48. . . . . . . . . . . . . . . . . . . . . . . . . . .

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
