Omron E5CK User Manual

CHAPTER 2 PREPARATIONS
E5CK
2–1
CHAPTER 2
PREPARATIONS
This chapter describes the operations (e.g. setup, installation and wirĆ
ing) you should carry out before turning the E5CKĆT ON.
CHAPTER2
2.1 Setup 2Ć2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DrawĆout 2Ć2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the input type jumper 2Ć2. . . . . . . . . . .
Setting up the output unit 2Ć3. . . . . . . . . . . . . .
Setting up the option unit 2Ć3. . . . . . . . . . . . . . .
2.2 Installation 2Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 2Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Panel cutout 2Ć4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting 2Ć5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Wiring Terminals 2Ć6. . . . . . . . . . . . . . . . . . . . . .
Terminal arrangement 2Ć6. . . . . . . . . . . . . . . . .
Precautions when wiring 2Ć6. . . . . . . . . . . . . . .
Wiring 2Ć6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
